Key Benefits
- High airflow output of 20 CFM for demanding industrial applications
- Maximum pressure up to 175 PSI for reliable performance
- Two-stage compression system improves efficiency and reduces discharge temperature
- Heavy-duty cast iron construction provides excellent durability and heat dissipation
- Belt-driven configuration ensures smooth power transmission and consistent operation
Specifications
- Model: MSV 20 MAX
- Part Number: 932.7527-0
- CFM (use this exact value): 20 CFM
- Max PSI: 175 PSI
- HP: 5 HP
- Pump Type: Two Stage, Belt Driven
- RPM: 1050
- Connections: 1/2″ NPT discharge
- Belt Type: 1-A (2-A Optional)
- Oil Capacity: 1.0 qt
- Weight: 94.8 lbs
- Dimensions: 16.5″ L x 15.5″ W x 16″ H
Applications
- Industrial workshops and automotive service centers
- Manufacturing and production line operations
- Maintenance facilities requiring continuous compressed air
- Heavy-duty compressed air systems in demanding environments
Warranty
- 1 Year Warranty on Pump
Downloads
- Technical Manual: MSV-20-MAX.pdf
