Key Benefits
- High pressure up to 175 PSI for demanding applications
- 20 CFM airflow supports multiple tools simultaneously
- Large 80-gallon tank for consistent air supply and reduced cycling
- Heavy-duty cast iron pump for long service life
- Integrated aftercooler improves air quality and protects downstream equipment
Specifications
- Part Number: 932.9372-0
- CFM (use this exact value): 20 CFM
- Max PSI: 175 PSI
- HP: 5 HP (3.7 kW)
- Tank Size: 80 Gallon (300 Liters)
- Voltage: 230V Single Phase
- Frequency: 60 Hz
- RPM: 1750
- Air Outlet: 3/4″ NPT
- Connections: See datasheet
- Oil Capacity: 1.27 Quarts
- Dimensions: 67″ H x 24″ W x 30″ D
- Weight: 364–386 lbs
Applications
- Automotive repair shops and body shops
- Industrial manufacturing and production lines
- Air tool operation systems
- Maintenance, service facilities, and heavy-duty workshops
Warranty
- 1 Year Limited Warranty
- Extended Warranty Available
Downloads
- Technical Manual: FCT-025.1097-0-MCSV-20-AUDAZ-80G.pdf
